MIL-DTL-24560/12C(SH)
REQUIREMENTS:
DESIGN:
Electrical rating: 120 volts, 60 hertz, 500 watts.
Dimensions and configuration: See figures.
Enclosure: Submersible (type II).
Parts: See table I.
First article: Examination of product, magnetic permeability,
operation, insulation resistance, dielectric
withstanding voltage, vibration, shock, salt spray,
degree of enclosure, hydrostatic pressure.
GENERAL INFORMATION:
Assignment of military part numbers and general
information are as follows:
(a)
Military part number: M24560/12-001 - light assembly,
symbol 233.1.
(b)
Supersedes Drawing 803-5001032.
(c)
Weight: The weight of the body assembly shall be 4.5
pounds maximum.
NOTES:
1.
This light will be mounted in base down position.
2.
Spacer (M24560/12-016) shall be used to position the top of the
lampholder socket approximately 1/16 inch above the top of base
(M24560/12-010).
3.
Molded plug, M24231/1-001 or M24231/2-001, sym 713 or 713.5,
using type TSS-4 cable conforming to MIL-C-915/8.
4.
Each assembly shall be subject to a hydrostatic pressure of 1500
lb/in2 + 1 percent for 1 hour. The test shall be conducted
with cap (M24560/12-011) or plug (M24231/1-001 or M24231/2-001)
removed.
TABLE I.
Parts.
Part number 1/
Part name
Qty.
Specification
Additional information
M24560/12-010
Base
1
MIL-M-14
Molded plastic GDI-30
or GPI-100 (black)
M24560/12-011
Cap
1
MIL-M-14
Molded plastic GDI-30
or GPI-100 (black)
M24560/12-012
Mounting
3
COML
AL BRZ
insert
M24560/12-013
Receptacle
1
QQ-N-281
Ni-CU alloy class A
M24560/12-014
Insert
6
COML
AL BRZ
M24560/12-015
Washer, lock
6
COML
CRES, #10
M24560/12-016
Spacer
2
COML
CRES
M24560/12-017
Insert
1
COML
Nylon 0.125+ 0.001 dia
x 0.203 lg
See footnote at end of table.
7
