INCH-POUND
MIL-DTL-3976/2A
11 OCTOBER 2007
SUPERSEDING
MIL-L-3976/2
16 June 1992
DETAIL SPECIFICATION SHEET
LIGHT MARKER
CLEARANCE-BLACKOUT, 24 VOLT
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and MIL-DTL-3976.
(130.2 mm)
A
A
2.437
(61.9 mm)
BOTTOM
LAMP - AA52463-A08
LENS - SEE TABLE
LAMPHOLDER - MS35422-1
1.656
(42.1 mm)
1.656
(42.1 mm)
BAND MARKER
M43436/1-1
490
REF: PIN CONTACT
AA52536-2
6.000
(152.4 mm)
A-A
SECTION
AMSC N/A
1 of 2
FSC 6220
