MIL-DTL-24560/11B(SH)
REQUIREMENTS:
DESIGN:
Electrical rating: 120 volts, 60 hertz, 50 watts.
Dimensions and configuration: See figures.
Enclosure: Splashproof (type I).
Parts: See table I.
First article: Examination of product, magnetic permeability,
operation, dielectric withstanding voltage, vibration,
shock, salt spray, degree of enclosure.
GENERAL INFORMATION:
Assignment of military part numbers and general
information are as follows:
(a)
Military part number: M24560/11-001 - light assembly, symbol
200.2.
(b)
Supersedes MS17780 symbol 220.2 except lens, piece 6.
Lens is now covered on MIL-L-24560/18.
(c)
Weight: The weight of this light assembly shall be not greater
than 1.5 pounds.
NOTES:
1.
The end of the stuffing tube entering the base shall be cut flush
with the locknut, to permit installation and wiring of lampholder.
2.
The exterior surfaces shall be given two coats of gray enamel and
the interior surfaces shall be given two coats of white baked
enamel of a good commercial grade.
TABLE I.
Parts.
Part number 1/
Part name
Qty.
Specification
Additional information
M24560/11-010
Base
1
QQ-A-250/8
AL
M24560/11-011
Barrel
1
QQ-A-250/8
AL
M24560/11-012
Reflector
1
QQ-A-250/8
AL
M24560/11-013
Lens holder
1
QQ-A-250/8
AL
M24560/11-014
Washer, lock
22
COML
CRES, #10
M24560/11-015
Pad
1
QQ-A-225/8
AL
M24560/11-016
Stud
-
-----
-----
assembly
M24560/11-017
Stud
1
QQ-A-225/8
AL, 3/8-16 NC-2A x 1-1/4
LG
M24560/11-018
Plate
1
QQ-A-250/8 or
AL
QQ-A-225/8
See footnotes at end of table.
7
