MIL-DTL-24560/11B(SH)
TABLE I.
Parts - Continued.
Part number 1/
Part name
Qty.
Specification
Additional information
M24560/11-019
Washer
1
COML
Nylon
M24560/11-020
Latch & strike
2
COML
AL (miniature type)
or CRES
M24560/11-021
Lock washer
1
COML
CRES, 3/8
M24560/11-022
Nut
1
COML
CRES, 3/8
M24560/11-023
Screw, mach
4
COML
CRES, #6-32 NC-2A x
F.H.
3/8 LG
M24560/11-024
Washer, lock
4
COML
Phosphor bronze, #6
M24560/11-025
Nut, hex
4
COML
CRES, #6
M24560/11-026
Screw, mach fil
2
COML
CRES, #10-24 NC-2A x
hd
¾ LG
M19622/2-002
Stuffing tube
1
MIL-S-19622/2
M24560/11-027
Lampholder
1
COML - UL496
Supplement SA, fig.
assembly
SA3.6
Lamp
1
COML
50/50T12
M24560/18-001
Lens
1
MIL-L-24560/18
Clear
1/
Part numbers M24560/11-010 through M24560/11-027 were assigned for reference
purposes only.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision
to identify changes with respect to the previous issue due to the extent of the
changes.
Preparing activity:
Navy - SH
(Project 6220-N390)
8
