MIL-DTL-24560/13D (SH)
REQUIREMENTS:
DESIGN:
Electrical rating: 120 volts, 60 hertz, 50 watts.
Dimensions and configuration: See figures.
Enclosure: Submersible (type I).
Parts: See table I.
First article: Examination of product, magnetic permeability,
operation, insulation resistance, dielectric
withstanding voltage, vibration, shock, salt
spray, degree of enclosure, hydrostatic pressure.
GENERAL INFORMATION:
Assignment of military part numbers and general
information are as follows:
(a)
Military part numbers:
M24560/13-001
-
light assembly,
symbol 174.4
-
clear.
M24560/13-002
-
light assembly,
symbol 188.3
-
clear (masked).
M24560/13-003
-
light assembly,
symbol 189.3
-
red.
M24560/13-004
-
light assembly,
symbol 174.5
-
green.
(b)
Weight:
The weight of the body assembly shall be not greater
than 4.5 pounds.
NOTES:
1.
This light will be mounted in base down position.
2.
Molded plug, M24231/1-001 or M24231/2-001, symbol 713 or 713.5,
using type TSS-4 cable in accordance with MIL-C-915/8 shall be
used with this light.
3.
Each assembly shall be subjected to a hydrostatic pressure of
1500 lb/in2 + 1 percent for 1 hour. The test shall be
conducted with cap (M24560/12-011) or plug (M24231/1-001 or
M24231/2-001) removed.
TABLE I.
Parts.
Part number 1/
Part name
Qty.
Specification
Additional information
M24560/13-010
Washer, lock
6
COML
CRES #10
M24560/13-011
Insert
1
COML
Nylon 0.125 + 0.002
dia long
M24560/13-012
Ring,
1
COML
Spiralox, PRD-99-M,
retaining
or equivalent
M24560/13-013
Screw, mach
4
COML
CRES, #10-24 UNC-2A x
R.H.
1/2
See footnote at end of table.
4
