MIL-DTL-24560/13D (SH)
TABLE I.
Parts - Continued.
Part number 1/
Part name
Qty.
Specification
Additional information
M24560/13-014
Screw, mach
2
COML
CRES, #10-24 UNC-2A x
fil. Hd
3/4
M24560/2-011
Securing
1
MIL-M-14
Molded plastic GDI-30
ring
or GPI-100 (black)
M24560/12-010
Base
1
MIL-M-14
Molded plastic GDI-30
or GPI-100 (black)
M24560/12-011
Cap
1
MIL-M-14
Molded plastic GDI-30
or GPI-100 (black)
M24560/12-012
Mounting
3
COML
AL BRZ
insert
M24560/12-013
Receptacle
1
QQ-N-281
Ni-Cu alloy class A
M24560/12-014
Insert
1
COML
AL BRZ
M24560/15-001
Globe -
1
MIL-DTL-24560/15
For use with sym 174.4
fresnel -
clear
M24560/15-006
Globe -
1
MIL-DTL-24560/15
For use with sym 188.3
fesnel -
clear masked
M24560/15-002
Globe -
1
MIL-DTL-24560/15
For use with sym 189.3
fesnel -
red
M24560/15-003
Globe -
1
MIL-DTL-24560/15
For use with sym 174.5
fresnel -
green
MS28775-238
O-ring
1
MS28775
MS28775-216
O-ring
1
MS28775
MS28775-215
O-ring
1
MS28775
MS28775-115
O-ring
1
MS28775
M24560/13-015
Lampholder
1
COML - UL496
Supplement SA, fig.
SA3.6
Lamp
1
COML
50/50T12
M24231/5-010
Insert,
1
MIL-C-24231
M24231/5-010 (wire only
molded
0.12 inch long)
1/
Part numbers M24560/13-010 through M24560/13-015 were assigned for reference
purposes only.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision
to identify changes with respect to the previous issue due to the extent of
the changes.
Preparing activity:
Navy - SH
(Project 6220-N392)
5
