MIL-DTL-24560A(SH)
TABLE I.
First article inspection.
Test
Requirement
Test method
Light Assemblies
3.1, 3.4.1, 3.5.3, 3.5.4
Examination of product
4.3.2
Magnetic permeability
3.3.3
4.4.1.9
Operation
3.5.1.1
4.4.1.1
Dielectric withstanding
3.5.1.6
4.4.1.6
voltage 1/
Insulation resistance 1/
3.5.1.7
4.4.1.7
3.5.1.4
Vibration
4.4.1.4
Dielectric withstanding
3.5.1.6
4.4.1.6
voltage 1/
3.5.1.3
Shock
4.4.1.3
Dielectric withstanding
3.5.1.6
4.4.1.6
voltage 1/
Salt spray
3.5.1.5
4.4.1.5
Degree of enclosure
3.5.1.2
4.4.1.2
3.5.1.8
Hydrostatic pressure (type II)
4.4.1.8
Dielectric withstanding
3.5.1.6
4.4.1.6
voltage 1/
Insulation resistance 1/
3.5.1.7
4.4.1.7
Glassware
Examination of product
3.1, 3.4.2, 3.5.3, 3.5.4
4.3.2
Light output
3.5.2.1
4.4.2.1
Color (chromaticity)
3.5.2.2
4.4.2.2
Mechanical shock
3.5.2.4
4.4.2.4
Thermal shock
3.5.2.5
4.4.2.5
Paint removal
3.5.2.3
4.4.2.3
Hydrostatic pressure (class 3)
3.5.2.6
4.4.2.6
Breakage pattern
3.5.2.7
4.4.2.7
Color determination
3.4.2.1
4.4.2.8
1/ If applicable (see 3.1).
4.2.3 Combination of tests. Where advantageous, the contractor may
combine tests in cases where the basic body of the light assembly to be tested
is the same for different symbol numbered assemblies. For example, the symbol
number changes when a red globe is substituted for a clear globe in the same
basic light fixture.
4.4.2 Replacement glassware. When glassware is being furnished only as
replacement parts, the Government will furnish the applicable light assemblies
where required to complete the necessary first article tests.
4.2.5 Sampling size. One light assembly or one glassware furnished as
a replacement part shall be subjected to first article inspection.
4.2.6 Inspection routine. When specified (see 3.1), the sample light
assemblies and glassware shall be subjected the inspections shown in table I,
in the order shown.
4.2.7 Failures. One or more failures shall be cause for refusal to
grant first article approval.
4.3 Conformance inspection. Conformance inspection shall consist of the
examinations and tests as specified in tables II and III.
