MIL-DTL-4510F
TABLE I. Size, sealed beam trade numbers and operating characteristics.
Rated
life1
Trade
Design
Nominal
Beam
Spread
Government
Size
no.
volts
Watts
C.P.
horiz
vert
hours
part number
5.5°
4°
4535
4535
6.4
30
95,000
100
A52409-4535
7°
7°
4533
4533
6.5
40
50,000
50
A52409-4533
5°
5°
4435
4435
12.8
30
75,000
100
A52409-4435
11°
11°
4530
4530
26.0
135
100,000
50
A52409-4530
2°
2°
4553
4553
28.0
250
225,000
25
MS25241-4553
1
At design volts.
1.3 Part or identifying number (PIN). The PIN to be used for spotlights acquired to this
specification is created as follows:
M 4510 - X X XXXX
Size:
(See table I)
Class: A - 6-inch control arm
B - 23-inch control arm
Type:
1 - Type I - Ready for use
2 - Type II - Primed
Specification number
Denotes military specification
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure the
completeness of this list, document users are cautioned that they must meet all specified requirements of
the documents cited in sections 3 and 4 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified,
the issues of these documents are those cited in the solicitation or contract.
2
