MIL-DTL-14465F
3.3.5 Driving lights.
3.3.5.1 Sealed-beam lamps. The sealed-beam lamps shall conform to MS18003-411,
two-filament type to provide high- and low-beam operation (see 4.2.3).
3.3.5.2 Clear lens. The clear lens of the driving light shall conform to Drawing 7962266.
3.3.5.3 Filter lens. The filter lens of the infrared driving light shall be infrared and shall
conform to Drawing 7962265 (see 4.2.3).
3.3.6 Blackout marker light. The front position markers shall emit white light and the
filter lens shall be opaque except for the two Y-shaped openings (see 4.2.3).
3.3.7 Blackout driving light. The blackout driving light shall be constructed as shown on
the applicable drawing or military standard (see 4.2.3).
3.3.8 Cable. Electrical cable shall conform to MIL-DTL-13486 (see 4.2.3).
3.3.9 Standard parts. Military standard parts shall be used wherever applicable.
Commercial standard parts may be used provided they are interchangeable without modification
with the military standard parts they replace. Government approval is required when commercial
parts are used (see 4.2.3).
3.4 Operating requirements. Each light assembly shall provide the following functional,
operational, and performance capabilities.
3.4.1 Functioning. When supplied with an input voltage of 28 Vdc all lights of the light
assembly shall operate without dimming or flickering (see 4.2.4.1).
3.4.2 Sealed-beam lamps - candlepower. When supplied with an input voltage of 28
Vdc, the sealed-beam lamps, both high and low beams, shall meet the candlepower requirements
listed in tables I and II, 18 meters (m) from their source (see 4.2.4.2).
TABLE I. Lower beam candlepower values. 1/
Candlepower
Position (°)
Maximum Minumum
1U to 90U
500
H L to R
750
1D-V
1050
950
1 1/2 D 3R to 3L
5000
2D 3R to 3L
2000
2D 9R to 9L
1000
3D 15R to 15L
500
1/ See 6.6.
5
